Product Description
This 4'' System capitalizes on Toyota Tundra's large wheelwell opening to allow use of 35'' tall tires with minimum lift height. The design of this 4'' System is a new style of suspension that delivers improved performance with fewer parts, and comes with an affordable price. The system includes replacement upper control arms constructed with .120'' wall 4130 Chromoly and 1'' FK Stainless Uniballs. Heavy duty extended length steering knuckles are included to provide proper functionality of the factory ESC (Electronic Stability Control) with 35'' tall tires. The knuckles retain the stock track width keeping the tires under the front fenders. The front differential is relocated to keep CV angles proper during the full range of travel. Front bump stop extensions and brake hose relocation brackets complete the front suspension. Rear lift comes from a 1'' lift block and u-bolt system to level the stance of the vehicle. The 4'' System is available with Dirt Logic 2.50 front Coilovers and rear Dirt Logic 2.25 shocks for increased travel and aggressive offroad driving.
Arms eliminate upper ball join w/super strong 1 ID stainless American uniball. Additional caster is built into arms for greater align ability to help with problematic leveling kit alignments. Allows for increased wheel travel when used w/Dirt Logic 2.5 coilover shocks. Chromoly tubing reduces flex found in stock arms for more positive road feel. 4340 heat treated uniball pin fits into factory ball join taper without modification to the spindle for easy return to stock feature. Arms are direct replacements for factory arms on suspensions that require additional strength and align ability.
TIRE SIZE - 35/12.50R18 WHEEL - 18X9 W/4 1/2" BS W/MINOR TRIMMING; TIRE SIZE - 35/12.50R20 WHEEL - 20X9 W/5" BS W/MINOR TRIMMING; TIRE SIZE - 295/65R20 WHEEL - 20X9 W/5" BS W/MINOR TRIMMING; TIRE SIZE - 295/70R18 WHEEL - 18X9 W/4 1/2" BS W/MINOR TRIMMING
Fabtech 07-15 Toyota Tundra 2WD/4WD 4in Uniball UCA System w/DL 2.5 Resi Coilovers & Rear DL Shocks
4" UCA KIT W/UNIBALLS W/ DLSS 2.5 C/O RESI & RR DLSS 07-15 TOYOTA TUNDRA 2WD/4WD
4IN. UCA KIT W/UNIBALLS W/DLSS 2.5 C/O RESI/RR DLSS 07-15 TOYOTA TUNDRA 2WD/4WD
4" UCA KIT W/UNIBALL
Suspension Lift Kit
LftKt-Suspw/Shock
If your like to off road or are looking to fit some bigger tires on your vehicle, a lift kit is one of the first modifications we recommend to our customers. Lift kits are great for enhancing your off roading experience because they allow your to have better wheel clearance for bigger tires and ground clearance for those aggressive trails.
WARNING: Cancer & Reproductive Harm. For more information, go to www.P65Warnings.ca.gov
Package Contents
- 1 count of Fabtech 07-15 Toyota Tundra 2WD/4WD 4in Uniball Upper Control Arm - FTS26039
- 1 count of Fabtech 07-15 Toyota Tundra 2WD/4WD 4in Front Dirt Logic 2.5 - FTS26052
- 2 count of Fabtech 07-15 Toyota Tundra 2WD/4WD 4in Rear Dirt Logic 2.25 - FTS810982
Fabtech is a leader in the offroad industry, designing and manufacturing quality lift kits for Chevy, Ford, Ram, Jeep, Hummer, Nissan, and Toyota.
Vehicle Fitments- 2007 Toyota Tundra Base
- 2007 Toyota Tundra Limited
- 2007 Toyota Tundra SR5
- 2008 Toyota Tundra Base
- 2008 Toyota Tundra Limited
- 2008 Toyota Tundra SR5
- 2009 Toyota Tundra Base
- 2009 Toyota Tundra Limited
- 2009 Toyota Tundra SR5
- 2010 Toyota Tundra Base
- 2010 Toyota Tundra Limited
- 2010 Toyota Tundra SR5
- 2011 Toyota Tundra Base
- 2011 Toyota Tundra Limited
- 2011 Toyota Tundra SR5
- 2012 Toyota Tundra Base
- 2012 Toyota Tundra Limited
- 2013 Toyota Tundra Base
- 2013 Toyota Tundra Limited
- 2013 Toyota Tundra Platinum
- 2014 Toyota Tundra 1794 Edition
- 2014 Toyota Tundra Limited
- 2014 Toyota Tundra Platinum
- 2014 Toyota Tundra SR
- 2014 Toyota Tundra SR5
- 2015 Toyota Tundra 1794 Edition
- 2015 Toyota Tundra Limited
- 2015 Toyota Tundra Platinum
- 2015 Toyota Tundra SR
- 2015 Toyota Tundra SR5
- 2015 Toyota Tundra TRD Pro
