Tomei Expreme Ti Titanium Evo 7-9 Catback Exhaust

STOCK COMPARISION

The exhaust flow design was the main focus in the pipe design, the best pipe thickness for weight and strength with pipe diameter to suit torque and all power gains throughout the entire power band.

TOMEI
STD
MATERIAL
TITANIUM
STAINLESS
DIAMETER MAIN PIPE
Φ80
Φ60.5
MAIN PIPE THICKNESS
1mm
1.5ｍｍ

SILENCER DIAMETER
Φ152
100×440mm (Oval)
SILENCER BROAD THICKNESS
1mm
N/A
TIP DIAMETER
Φ115
Φ100
TIP BROAD THICKNESS
1mm
N/A
FLANGE THICKNESS
6mm
12mm
WEIGHT
4.85kg
16.00kg

11.15 kg LIGHTER!

▲STANDARD EVO IX


RACING LAYOUT

For the best exhaust efficiency results minimal bends and curves was the design focus points on this product which aided with the supreme results.


3 PIECE ASSEMBLY

No flanges were fitted for increased weight savings and for a better finish with the race look secure springs and clamp methods.

DRY RACE SOUND

The instinctive sound of a true race exhaust sound that a Titanium material exhaust gives will intoxicate you with the dry race exhaust sound.

PERFORMANCE VALUE

The best performance is made possible with the best materials and still with keeping it within everyone’s reach.


KIT CONTENTS


MAIN PIPE A

MAIN PIPE B

SILENCER ASSEMBLY

GASKET

WASHER M12 x2

NUT M12 x2

A/F BOSS PLUG　*1


COPPER WASHER　*1

CLAMP BAND x2

SPRING x4

SILENCER BAND

SILENCER BAND INSULATOR

BOLT M8 L=25mm

NUT M8

SOUND REDUCER ver.2



MUFFLER HANGERS　*2

SPACER　*2

SPRING WASHER　*2

BOLT M8 L=60mm 　*2

BOLT SMOOTH PASTE

1* Exculding North American models.
2* Excluding EVO IX Japanese models.
This model does not include North America.

COMPATIBLE WITH ALL CT9A EVO MODELS

JAPANESE BUMPER 　EVO VII VIII



JAPANESE BUMPER　EVO IX



NORTH AMERICAN BUMPER 　EVO VIII / IX




EVO VII / VIII / IX - for JAPANESE BUMPER -

PART NUMBER ：
TB6090-MT01A (Previous P/N 440003)

MSRP $1,090.00 (USD)

EVO VIII / IX - for NORTH AMERICAN BUMPER-

TB6090-MT01B (Previous P/N 440004)

MSRP $1,090.00 (USD)

Additional bolt holes may be required when using the sound reducer ver.2 .
